FANUC AMERICA TO SHOWCASE ROBOTIC SOLUTIONS FOR FOOD PROCESSING AND PACKAGING AT IPPE 2024

FANUC offers the widest range of robots and cobots for packaging and palletizing applications - for any speed, payload and reach. Our robots offer multiple mounting options and application-specific technologies, including vision and force sensing.

FANUC DR-3iB/6 STAINLESS Delta Robot Handles Protein
The DR-3iB/6 Stainless is FANUC’s stainless steel food-grade delta robot for picking and packing primary foods. Rated IP69K, the robot complies with U.S. national food safety standards, which will help companies increase their production efficiencies without compromising food safety.

At IPPE, the DR-3iB/6 STAINLESS robot will use 3DV iRVision and iRPickTool line tracking software to pick randomly oriented pieces of chicken from a continuous infeed conveyor. Equipped with a Soft Robotics gripper, the robot picks chicken breasts and reorients them onto an outfeed conveyor with trays. The cell features high-speed picking with product re-orientation.

The DR-3iB/6 STAINLESS features a fully enclosed stainless-steel body that is resistant to the chemicals and high pressure/temperatures required in strict wash down environments. It has a 1200mm reach (450mm height) and a powerful four-axis design allowing it to handle up to 6kg payloads at high speeds. The robot’s mirror-like surface finish ensures that any microbial contaminants can be washed away cleanly. Additional features such as NSF H1 food grade lubricant, secondary oil catch basins (with viewing windows to monitor potential leaks), self-draining surfaces and many other small details driven by food safety standards, makes the DR-3iB/6 STAINLESS an ideal solution for primary food handling applications.

The robot operates with FANUC’s latest R-30iB Plus controller with integrated intelligent functions such as iRVision, Force Sensing, Robot Link, Collision Guard and Zero Down Time (ZDT).

FANUC CRX-25iA Cobot Demonstrates Case Palletizing
A CRX-25iA cobot offering a 30kg payload and 1,889mm reach will demonstrate case palletizing. Guided by a 3DV/200 iRVision^® sensor mounted to the arm, the CRX-25iA will palletize boxes to nearly 7’ high. In addition, the CRX-25iA will be mounted to a mobile cart to showcase its flexibility. The robot can be easily repositioned by hand and uses vision to automatically adjust to its new location and continue working accurately.

FANUC’s series of CRX collaborative robots all provide the utmost reliability, flexibility, and can run for eight years without maintenance.

M-10iD/12 Food-Grade Option Robot Picks and Packs Wrapped Protein
FANUC’s Food-Grade M-10iD/12 robot picks wrapped protein and packs it into a box. The demonstration highlights the robot’s speed and flexibility to handle various payloads. Additional software features include Collision Guard, Constant Path, and Singularity Avoidance.

The M-10iD/12 and larger M-20iD/25 Food-Grade options are members of the M-10iD and M-20iD robot series. Both models feature white epoxy paint, IP65 standard body protection (IP67 wrist + J3 arm), food-grade oil on all axes, stainless steel wrist flanges, motor covers, corrosion-resistant fasteners, and the Severe Dust & Liquid Protection package.

The M-10iD/12 has a 12kg payload and a 1441mm reach, and the M-20iD/25 offers a 25kg payload and 1831mm reach. A long reach, including the backflip region, coupled with a lightweight and sleek design makes it easier for customers to use the robots in their available workspace, which is often at a premium. A large hollow wrist and arm allows internal cable routing to prevent snagging and minimize interference with work pieces and fixtures.

For more information visit IPPE 2024 | FANUC America.
